Wharfedale Pro WLA-25 2x5" 160W Line Array Passive Speaker
Key Feature Of Wharfedale Pro WLA-25
-
➤ Dual 5" drivers with 2.5" voice coils for powerful sound.
-
➤ 1.75" neodymium compression driver for clear highs.
-
➤ Wide 100° x 10° sound dispersion.
-
➤ Lightweight 13 kg for easy transport.
-
➤ Durable plywood enclosure with steel grille.
PRODUCT OVERVIEW
Wharfedale Pro WLA-25
The new WLA-25 is a two-way passive line array system that features the same design philosophy as its established larger brother, the WLA-28. It brings long throw capabilities together with extreme SPL—all from within a compact and portable array system.
|
IRIS X Compression Driver The biggest breakthrough during the development process was the creation of a custom Wharfedale Pro IRIS X neodymium HF compression driver. This newly engineered HF component delivers extreme sensitivity from a very compact and lightweight design. Along with its supersensitive 1.75” voice coil, this HF compression driver also features aluminum back plating, which acts as a heat sink to aid heat dissipation. |
 |
A hot transducer wastes energy, risks damage, and distorts. IRIS X reduces this through improved heat dissipation and improved efficiency. This attention to detail protects the driver from heat damage and mechanical distortion during extreme performance levels. In real-world terms, IRIS X transducers deliver higher SPL with less distortion. They lead the market with specifications and are designed and built entirely within Wharfedale Pro.
 |
 |
|
2 x 5" LF Transducers The 2 * 5” custom LF drivers have been developed to work in partnership with the IRIS X neo HF driver. Rigid die-cast baskets ensure consistent sonic performance with minimum distortion. The placement and physical mounting of all the drivers have been fine-tuned to ensure maximum phase coherence and SPL are achieved from the compact cabinet. |
Ready for Ground Stacking WLA-25 rigging doubles up as an optimized ground stacking system, using the WLA-25SUB subwoofer as a base. Arrays of WLA-25 line array elements can be aimed downwards by as much as 10° to cover audience areas close to a stage, as well as upwards by as much as 10° in order to better cover distant balcony seating areas. |
Flexible Arrays
Arrays can be assembled using only WLA-25 line array modules or with WLA-25SUB subwoofers at the top of the array. The WLA-25SUB Fly Frame allows for a WLA-25SUB subwoofer to be used at the top of the array. The WLA-25SUB Fly Frame supports up to 12 x WLA-25 modules and 1 x WLA-25SUB with a safety factor of 12. The WLA-25 Common Fly Frame allows for EITHER WLA-25SUB or WLA-25 configurations to be flown.
Key Features
-
2 * 5″ Wharfedale Pro LF drivers
-
16Ω impedance
-
Dispersion (-6dB): 90° x 10°
-
Max SPL : LF 115 dB, HF 131 dB
-
Power LF : 100w (continuous), 400w (peak)
-
Power HF : 50w (continuous), 200w (peak)
-
IRIS X Compression driver
-
Only 13kg
| Product Name | Wharfedale Pro WLA-25 2x5" 160W Line Array Passive Speaker |
|---|---|
| Weight | 13.00 Kg |
| Configuration | Two-way |
| Frequency Response | 108Hz - 18kHz |
| Power (RMS / Program / Peak) | 160w | 320w | 640w |
| Impedance | 16Ω |
| Maximum SPL | HF:135dB/LF:127dB |
| Low Frequency Transducer | 2 * 60w |
| High Frequency Transducer | 40w |
| Input | 2 x speaker compatible |
| Dimensions | 235mm x 606mm x 430mm |
| Package Weight | 15kg |
| Manufacturer | Wharfedale |
| Color | Black |
| Country of Origin | United States |
