Wharfedale Pro Titan Sub A12 1x12" 250W Powered Subwoofer
Key Feature Of Wharfedale Pro Titan Sub A12 PAINT
-
➤ 12″ active subwoofer, 250 W RMS / 500 W peak.
-
➤ Adjustable crossover (80–200 Hz) with 150 Hz HPF.
-
➤ Qubit DSP for clear, phase-aligned bass.
-
➤ Built-in protection circuits.
-
➤ Phase switch and flexible input/output options.
PRODUCT OVERVIEW
Wharfedale Pro Titan Sub A12 Paint
The Wharfedale Pro Titan Sub-A12 is a powerful active subwoofer system for small to medium active PA speaker setups. It utilizes a 12” active reflex subwoofer to generate 250W RMS (500W peak) power, with a frequency response of 55-200 Hz. It’s a perfect match when teamed up with the Wharfedale Titan 8A MKII, creating an incredibly portable sound reinforcement system.
|
ACG Technology A custom-designed, pressed-frame 12" woofer, with a 2.5" voice coil, is utilized as the heart of the Titan™ Sub-A12's complementary low-frequency enhancement system. Integral signal processing includes a dynamic AGC (Automatic Gain Control) circuit, a stereo crossover, and signal limiting for the prevention of a distorted signal to the internal amplifier. A convenient and essential PHASE switch is included to allow for proper subwoofer signal polarity to be selected. |
 |
Class D Amplification Technology
Our engineers have used class D technology on the Sub A12 to make an efficient and lightweight subwoofer, making for easy transportation and setup, ideal for mobile DJs, bands, and other musicians on the road. Qubit™ is our new powerful and precise 24-bit 192 kHz DSP processing. With advanced adaptive multi-band dynamic processing and filtering, Qubit helps fine-tune your system to sound natural and open. Qubit processing optimizes the loudspeaker to provide smooth digital crossover points that are perfectly aligned in terms of phase response and time domain.
 |
 |
|
Built-in Crossover To integrate with your satellite speakers and to minimize the amount of equipment needed to take for more portable applications, the Titan SubA12 has a built-in crossover. This is adjustable from 80 Hz to 200 Hz, so you can use the subwoofer for sub-bass frequencies only right the way through to low mids. |
Powerful Bass The Wharfedale Pro Titan Sub A12 delivers deep, punchy bass with its 12″ active reflex design, offering 250 W RMS and 500 W peak power. Its adjustable crossover (80–200 Hz) and 150 Hz high-pass filter ensure seamless integration with satellite speakers for a balanced sound. |
Smart Features
Equipped with Qubit DSP for precise, phase-aligned audio, the Sub A12 also includes peak limiter, thermal, and short-circuit protection. A phase switch (0°/180°) and versatile XLR/¼″ combo inputs provide flexible connectivity for any setup.
Key Features
-
12” active reflex subwoofer
-
Low-frequency power amplifier (class D) 250W RMS, 500W peak
-
The preset integral peak limiter prevents signal distortion and amplifier clipping.
-
Integral phase switch with 0° and 180° selections
-
Thermal, DC fault, and short circuit protection
-
XLR / 1⁄4 ” combo jack inputs
-
Balanced line-level output
-
The preset limiter prevents signal clipping.
-
Integral pole mount adapter
-
High-pass frequency selection: 150 Hz
| Product Name | Wharfedale Pro Titan Sub A12 1x12" 250W Powered Subwoofer |
|---|---|
| Weight | 22.31 Kg |
| Configuration | Reflex Subwoofer |
| Frequency Response | 55 - 200Hz |
| Input | 2 x XLR Jack Combi |
| Type Of Protections: | Peak limiter, thermal, dc fault and short circuit protection |
| Dimensions | 360 x 493 x 431mm |
| Package Weight | 26.26kg |
| Manufacturer | Wharfedale |
| Color | Black |
| Country of Origin | United States |
