GW Instek LCR-6300 High Precision LCR Meter

Actual Stock Can Be Confirmed After Placing the Order.
All Delivery times are estimated based on the official restrictions.
SKU
LCR-6300
AED12,212 AED11,630
Price Match Request

The LCR-6300 (CE) from GW Instek is a LCR-6000 series 10Hz to 300KHz (±0.01%) (4 digits resolution) high precision LCR meter. The compact size design, 2U height and 1/2 rack is one of the practical features of series which is optimum space saver suitable for either bench top or system rack.

PRODUCT OVERVIEW

The LCR-6300 (CE) from GW Instek is a LCR-6000 series 10Hz to 300KHz (±0.01%) (4 digits resolution) high precision LCR meter. The compact size design, 2U height and 1/2 rack is one of the practical features of series which is optimum space saver suitable for either bench top or system rack. The compacted LCR-6300 with abundant features is absolutely excellent tool for R&D, production test, IQC etc on implementing each test stages for passive components.

It provides rich functionalities with compact size. In addition to simultaneously displaying setting criteria and measurement results, the meter increases two additional monitoring parameters. For external control, the meter provides handler interface & collocates with its measurement sorting function (9BIN, AUX: 1BIN) to facilitate connection with sorting machine so as to sort out materials. It has 10 memory sets defined by panel setting criteria to facilitate users in selecting test criteria and saving time in repeated setting

  • Consecutive frequency and convenient zero function
  • Rich and diverse information display, 10 points listed tests and PC software
  • Diverse ancillary measurement functions, 3.5" colour LCD features opulent display parameters
  • Basic accuracy of 0.05% (slow/medium), 0.1% (fast) & 25ms (fast)/100ms (med)/333ms (slow) test speed
  • RS-232C, handler, USB storage standard interface & 30 ohm/50 ohm/100 ohm selectable output impedance
  • Measuring speed up to 25ms (max), full frequency range or spot OPEN/SHORT
  • DCR measurement and internal DC bias voltage (±2.5V)
  • BIN function provides 9BIN and 1AUX, totally 10 BIN
  • 265mm (W) x 107mm (H) x 312mm (D) dimension, 3Kg weight, 90V to 250V, 50-60Hz (30VA power) AC power
More Information
Product Name GW Instek LCR-6300 High Precision LCR Meter
Weight 6.60
Power Supply (PoE) 100...240V AC 50/60Hz
Display LCD 3,5"
Dimensions 265x107x312mm

Manufacturer GW INSTEK
Color N/A
Country of Origin United States
