PRODUCT OVERVIEW

The DMInteract-CS-5 HIFI wall-mounted speaker supports dual-band WiFi and Bluetooth wireless connections. The speakers of the wall-mounted speaker are selected from 6.5-inch full-frequency speakers and 1-inch high-fidelity tweeters. Professional tuners divide the sound and debug and equalize. It can achieve full frequency coverage of 60~20KHz, and the SPL is as high as 90db. The wall-mounted speaker uses the PCM5121 DAC chip of Texas Instruments and the TDA7498E power amplifier chip of ST. The combination of the two industry HIFI level IC has outstanding sound quality and high power.

DMInteract-CS-5 is divided into a master and a slave, a pair of two speakers. The slave is a passive speaker, which is connected by a speaker cable. The output power of the master and slave speaker is up to 120W, which can be adapted to various occasions.

The CS-5 HIFI wall-mounted speaker also supports the AirPlay2 function launched by Apple and the industry device interconnection standard DLNA. It can wireless play music on devices such as iPhone, iPad or iPod touch through the AirPlay function, and can also use a third-party PLAYER that complies with DLNA standards to play music on Android devices or PC. Dual-band WiFi transmission at full speed, multi-experience without delay of high-definition music.

Product Functions

• Wi-Fi Protocol: IEEE 802.11 a/b/g/n/ac 1x1 dual band WiFi 2.4 GHz and 5GHz
• Bluetooth protocol: BT5.0 with EDR and BLE
• Support WiFi/Bluetooth/U disk playback/Aux input
• Support APP interconnection control
• Support 10/100Mbps Ethernet access
• Support HTTP/HTTPS/RTSP/MMS/TS protocol
• Support Airplay2/DLNA/Qplay streaming protocol
• Support Airplay, Bluetooth multi-room playback
• Support Spotify/Tuneln/iHeartRadio/Amazon music/Tidal etc.
• Support common lossless audio format decoding, up to 192kHz/24bit format
• Support MP3/AAC/FLAC/ALAC/WMA/APE/WAV/OGG and other audio formats
• Support NEC infrared remote control
