DMInteract DM80VC 4pcs Pressure Roller and 600mm Cutting Width Vinyl Cutting Plotter
Key Features Of DM80VC Cutting Plotter
-
➤ High-Precision Servo Motor – Delivers cutting accuracy of ±0.02 mm with up to 1000 g force.
-
➤ CCD Camera Registration – Ensures precise contour cutting using registration marks.
-
➤ Fast & Stable Cutting – Cuts at speeds up to 1200 mm/s with long-length tracking stability.
-
➤ Multiple Connectivity Options – Supports USB, U-disk, and network connections.
-
➤ Software Compatibility – Works with SignMaster and AIDCut-CAM and supports AI/CDR files.
PRODUCT OVERVIEW
The DMinTeract DM80VC Vinyl Cutting Plotter is a high-precision machine equipped with servo motors and a CCD camera for accurate contour cutting. Its advanced features include a mechanical resolution of 0.0245 mm, a cutting speed of up to 1200 mm/s, and seamless registration mark detection, making it ideal for detailed and extended cutting tasks without material misalignment.
|
The DM80VC Desktop Vinyl Cutter is a high-precision cutting machine designed for both professional and hobby use, featuring a powerful servo motor system that enables smooth, accurate cuts with a precision of up to ±0.02 mm. Equipped with a built-in CCD camera, it offers precise contour cutting by automatically detecting registration marks, making it ideal for printed graphics. With cutting speeds up to 1200 mm/s and stable long-length tracking, it handles large-scale jobs with ease. The VC80 supports multiple file transfer options, including USB and U-disk, and integrates seamlessly with popular design software like SignMaster and AIDCut-CAM, making it a versatile and efficient tool for sign making, vinyl decals, labels, and more. |
 |
Perfect for signage, garment decoration, and custom decal production, the DM80VC supports a wide range of materials and formats. With multiple connectivity options (USB, U-disk, and network) and compatibility with major cutting software, it offers both convenience and professional-grade results in a compact, user-friendly design.
 |
 |
|
Moving Carriage Steel frame with inliner bearing, it has more cutting pressure, which is adjustable easily, and it is good at heat dispersion. With a built-in high-resolution CCD camera, it can scan multiple mark points automatically to realize the contour cutting function. |
Steel Thorn and Pressure Roller The plotter is equipped with steel that can fix media effectively to avoid any sliding and ensure feeding precision. There are several pressure rollers on the upside of the beam; the distance between each roller can be adjusted to fit different-sized media. These high-precision imported rollers assure no offset feeding over long distances. |
 |
Multiple Interfaces Multiple data transfer methods are supported. U-disk, network, USB cable, and Wi-Fi connection. Users are allowed to select the data transfer method depending on various situations. |
 |
Touch Control Screen The DMInteract DM80VC vinyl cutting plotter features an intuitive touch control screen designed for ease of use. This user-friendly interface enhances workflow by simplifying access to key functions. Operators can navigate settings efficiently, ensuring a smooth and streamlined cutting experience. |
 |
Paper Feeding System The plotter features an advanced auto paper feeding system designed for effortless handling of roll materials. This mechanism ensures a smooth and accurate feeding process, reducing manual intervention. Its streamlined operation enables faster production with minimal interruptions. |
Suction Holes
Upon analyzing the product page for the DMInteract DM80VC Vinyl Cutting Plotter on DubaiMachines.com, it is clear that the machine is designed for professional-grade vinyl cutting with notable features like 4 pressure rollers and a 600mm cutting width. The product emphasizes high precision, ease of use, and a durable build suitable for industrial applications.
 |
 |
|
Paper Pressing Device There is a row of paper-pressing devices behind the plotter beam. During the working process, these paper presses can well fix the materials, ensure that the materials move within the fixed range, and reduce the offset. |
 |
|
Press bar After loading the material, pull down the handle to press the material so that the material can be fixed during the paper feeding process and reduce the offset. |
 |
|
Graduation The graduations are marked on the paper-feeding side of the working platform. So that the material size can be easily measured and adjusted when feeding the material |
 |
 |
 |
|
Switch on the Button & Power Interface Switch on and off easily with a press button after connecting the power cable to the plotter. We offer various worldwide standard power plugs. The voltage can also be customized due to customer needs. |
Catch-up basket The machine is equipped with a set of catch-up baskets, including 2 pieces of holding rollers and one piece of high-quality nylon cloth bag, saving space while keeping materials clean and tidy. |
Signmaking Applications
Every company needs to advertise for itself, but advertising is often far too expensive for small- to medium-sized businesses. The vinyl cutter can offer relief. The vinyl cutter is the central device in a company for use in advertising. It not only saves a large amount of money but also provides plenty of room to develop your creativity and ideas. With a vinyl cutter, you can, for example, advertise in the following ways quickly and easily:
-
Corporate sign making
-
Corporate vehicle signage
-
Design of the shop window advertising
-
Creating banners and stadium advertising at events
-
Design of the premises of the Company (Room label, signs, screening applications, design elements)
-
Production of stickers and labels as so-called Print&Cut applications—first you print on, e.g., sign vinyl, then contour-cut with the vinyl cutter.
Home Applications
Anyone who wants to individually create their personal environment will find a vinyl cutter to be the right tool. With these machines, many different creative ideas can be realized, as this selection shows.
-
Customized wall tattoo
-
Create kitchen surfaces
Hobby Applications in the Fields of Decoration, Model Making, etc.
-
Create templates for painting colorful wall designs, including banners, ornaments, and children’s artwork.
-
Individual design of garments like t-shirts, jackets, sweatshirts, etc., with flock or flex film.
 |
 |
| Product Name | DMInteract DM80VC 4pcs Pressure Roller and 600mm Cutting Width Vinyl Cutting Plotter |
|---|---|
| Weight | 44.00 Kg |
| Structure | With stand |
| Max. media width | 720mm |
| Max. cutting width | 600mm |
| NO. of Pressure Roller | 4pcs |
| Cutting Accuracy | 600a+/- 0.02mm |
| Drive Model | Servo drives |
| Speed | Max 1200mm/s |
| File Transfer Mode | USB/Network/U-Disk |
| Positioning System | CCD Camera |
| Registration Marks | Circle marks/Coner marks/QR code |
| Software Included | AIDCut-CAM, SignMaster |
| Feeding System | Pull shaft feeding structure, simple & time-saving |
| Motor Power | 25watt |
| Force | 1000G |
| Work Voltage | 110V-130V or 210-230V, 50hz/60hz |
| Ambient Temperature | +5°C ~+ 35°C |
| Packing Size | 1050 x 380 x 500mm(0.2CBM) |
| Package Weight | 47 kgs |
| Manufacturer | DMInteract |
| Country of Origin | China |
